• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted felt-lined flinger seal
• Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy 2-bolt split cast iron housing

Dimensions

Overall Width (in)	3.31 in
Base Width (in)	2.75 in
Overall Height (in)	5.625 in
Overall Length (in)	10.375 in
Bolt Center-to-Center Length (in)	7.815 in
Bolt Size (in)	0.625 in
Bore Size (in)	2.4375 in
Bolt Center Max (in)	8.688 in
Inner Race Length (in)	3.313 in
Centerline to Front Face (in)	2 in
Base to Center Height (in)	2.75 in
Bolt Center Min (in)	6.938 in
Foot Height (in)	1.813 in
Collar Outer Diameter (in)	3.938 in

Technical Specifications

Seal Type	Felt Labyrinth Seal
Housing Base	Solid
Housing Type	Pillow Block, Two Bolt
Insert Material	52100 Bearing Steel
Rolling Element	Tapered Roller
Measure Units	Inch
Housing Material	Cast Iron
Expansion	No
Housing Construction	Split Two Piece
Misalignment	±3.0° Misalignment - Static Only
Radial Dynamic Load Capacity (lb)	9,030 lb
Internal Clearance	Standard
Locking Type	Collar Mount
Speed (Max)	2000
Bore Shape	Straight
Misalignment Type	Static Only
Replaceable Insert	Yes
End Cap	No
Retainer Material	Steel
Platform	RPB Series
Bearing Insert Coating	Uncoated
Outer Ring Land Profile	Standard
Housing Color	Gray
Series	RPBA
Grease Fitting Thread Size	1/8 NPT
Duty/Series	Standard
Lubrication Type	Lithium; EP; NLGI#2
Inner Race Heat Treat Method	Case Carburized Inner Ring
Ability to Relubricate	Yes
Maximum Operating Temperature (F)	220 °F
Housing Style	Pillow Block
Insert Number	RCIA-207

General Specifications

UPC	662288483090
Weight	20.70 LB
Packaged Length	10.50 IN
Packaged Width	5.88 IN
Packaged Height	4.13 IN
HTC	8483.20.8080
Country of Origin	United States of America
