• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted contact flinger seal
• Double-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Fluoropolymer-coated 2-bolt split cast iron housing for improved corrosion resistance
• USDA H-1 approved Food-grade grease

Dimensions

Base Width (in)	2.75 in
Overall Height (in)	5.625 in
Bolt Center-to-Center Length (in)	7.815 in
Overall Width (in)	4 in
Bolt Size (in)	0.625 in
Overall Length (in)	10.375 in
Bore Size (in)	2.5000 in
Centerline to Front Face (in)	2 in
Base to Center Height (in)	2.75 in
Inner Race Length (in)	4 in
Foot Height (in)	1.625 in
Bolt Center Min (in)	6.938 in
Bolt Center Max (in)	8.688 in
Collar Outer Diameter (in)	3.938 in

Technical Specifications

Housing Base	Solid
Insert Material	52100 Bearing Steel
Rolling Element	Tapered Roller
Expansion	No
Seal Type	Single Lip Contact Seal
Measure Units	Inch
Housing Type	Pillow Block, Two Bolt
Housing Material	Flouropolymer Coated Cast Iron
Housing Construction	Split Two Piece
Internal Clearance	Standard
Locking Type	Double Collar Mount
Radial Dynamic Load Capacity (lb)	9,030 lb
Misalignment	±3.0° Misalignment - Static Only
Speed (Max)	2000
Bore Shape	Straight
Platform	CR Series
Bearing Insert Coating	Uncoated
Misalignment Type	Static Only
Options	Corrosion Resistant
Outer Ring Land Profile	Standard
Retainer Material	Steel
Replaceable Insert	Yes
Housing Color	Silver/Gray
End Cap	No
Series	RPB
Grease Fitting Thread Size	1/8 NPT
Housing Style	Pillow Block
Inner Race Heat Treat Method	Case Carburized Inner Ring
Duty/Series	Standard
Ability to Relubricate	Yes
Lubrication Type	Lithium; EP; NLGI#2
Insert Number	RCI-208C FG1
Maximum Operating Temperature (F)	220 °F

General Specifications

UPC	662288866497
Weight	20.70 LB
Packaged Length	10.50 IN
Packaged Width	5.88 IN
Packaged Height	4.13 IN
HTC	8483.20.8080
Country of Origin	United States of America
