• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted contact flinger seal
• Double-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy 2-bolt split cast iron housing

Dimensions

Overall Length (in)	10.375 in
Overall Width (in)	4 in
Base Width (in)	2.75 in
Bolt Size (in)	0.625 in
Overall Height (in)	5.625 in
Bore Size (in)	2.4375 in
Inner Race Length (in)	4 in
Foot Height (in)	1.625 in
Bolt Center Max (in)	8.688 in
Base to Center Height (in)	2.75 in
Centerline to Front Face (in)	2 in
Bolt Center Min (in)	6.938 in
Collar Outer Diameter (in)	3.938 in

Technical Specifications

Expansion	No
Insert Material	52100 Bearing Steel
Housing Type	Pillow Block, Two Bolt
Seal Type	Single Lip Contact Seal
Measure Units	Inch
Housing Base	Solid
Housing Material	Cast Iron
Rolling Element	Tapered Roller
Housing Construction	Split Two Piece
Speed (Max)	2000
Radial Dynamic Load Capacity (lb)	9,030 lb
Internal Clearance	Standard
Misalignment	±3.0° Misalignment - Static Only
Locking Type	Double Collar Mount
Bore Shape	Straight
Outer Ring Land Profile	Standard
Retainer Material	Steel
Misalignment Type	Static Only
Replaceable Insert	Yes
Platform	RPB Series
Housing Color	Gray
End Cap	No
Bearing Insert Coating	Uncoated
Series	RPB
Grease Fitting Thread Size	1/8 NPT
Inner Race Heat Treat Method	Case Carburized Inner Ring
Housing Style	Pillow Block
Insert Number	RCI-207C
Ability to Relubricate	Yes
Duty/Series	Standard
Maximum Operating Temperature (F)	220 °F
Lubrication Type	Lithium; EP; NLGI#2

General Specifications

UPC	662288493570
Weight	19.68 LB
Packaged Length	5.88 IN
Packaged Width	10.50 IN
Packaged Height	4.13 IN
HTC	8483.20.8080
Country of Origin	United States of America
