• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted contact flinger seal
• Double-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Fluoropolymer-coated 2-bolt split cast iron housing for improved corrosion resistance
• USDA H-1 approved Food-grade grease

Dimensions

Base Width (in)	2.75 in
Bolt Size (in)	0.625 in
Overall Width (in)	4 in
Overall Length (in)	10.375 in
Overall Height (in)	5.625 in
Bore Size (in)	2.4375 in
Centerline to Front Face (in)	2 in
Bolt Center Min (in)	6.938 in
Foot Height (in)	1.625 in
Bolt Center Max (in)	8.688 in
Base to Center Height (in)	2.75 in
Inner Race Length (in)	4 in
Collar Outer Diameter (in)	3.938 in

Technical Specifications

Seal Type	Single Lip Contact Seal
Housing Material	Flouropolymer Coated Cast Iron
Measure Units	Inch
Housing Base	Solid
Housing Type	Pillow Block, Two Bolt
Insert Material	52100 Bearing Steel
Rolling Element	Tapered Roller
Expansion	No
Housing Construction	Split Two Piece
Internal Clearance	Standard
Bore Shape	Straight
Locking Type	Double Collar Mount
Speed (Max)	2000
Radial Dynamic Load Capacity (lb)	9,030 lb
Misalignment	±3.0° Misalignment - Static Only
Outer Ring Land Profile	Standard
Housing Color	Silver/Gray
End Cap	No
Replaceable Insert	Yes
Retainer Material	Steel
Bearing Insert Coating	Uncoated
Misalignment Type	Static Only
Platform	CR Series
Options	Corrosion Resistant
Series	RPB
Grease Fitting Thread Size	1/8 NPT
Duty/Series	Standard
Housing Style	Pillow Block
Lubrication Type	Lithium; EP; NLGI#2
Inner Race Heat Treat Method	Case Carburized Inner Ring
Ability to Relubricate	Yes
Insert Number	RCI-207C FG1
Maximum Operating Temperature (F)	220 °F

General Specifications

UPC	662461298138
Weight	20.70 LB
Packaged Length	10.50 IN
Packaged Width	5.88 IN
Packaged Height	4.13 IN
HTC	8483.20.8080
Country of Origin	United States of America
