• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted contact flinger seal
• Double-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy 2-bolt split cast iron housing

Dimensions

Bolt Size (in)	0.625 in
Overall Length (in)	8.875 in
Overall Width (in)	3.5 in
Bolt Center-to-Center Length (in)	6.75 in
Overall Height (in)	4.625 in
Base Width (in)	2.438 in
Bore Size (in)	2 in
Bolt Center Min (in)	6.313 in
Foot Height (in)	1.25 in
Inner Race Length (in)	3.5 in
Bolt Center Max (in)	7.188 in
Centerline to Front Face (in)	1.75 in
Base to Center Height (in)	2.25 in
Collar Outer Diameter (in)	3.25 in

Technical Specifications

Housing Type	Pillow Block, Two Bolt
Rolling Element	Tapered Roller
Expansion	No
Insert Material	52100 Bearing Steel
Housing Base	Solid
Measure Units	Inch
Housing Material	Cast Iron
Seal Type	Single Lip Contact Seal
Housing Construction	Split Two Piece
Internal Clearance	Standard
Bore Shape	Straight
Radial Dynamic Load Capacity (lb)	8,070 lb
Misalignment	±3.0° Misalignment - Static Only
Locking Type	Double Collar Mount
Speed (Max)	2500
Retainer Material	Steel
Misalignment Type	Static Only
Housing Color	Gray
Platform	RPB Series
Replaceable Insert	Yes
Bearing Insert Coating	Uncoated
Outer Ring Land Profile	Standard
End Cap	No
Series	RPB
Grease Fitting Thread Size	1/8 NPT
Ability to Relubricate	Yes
Duty/Series	Standard
Lubrication Type	Lithium; EP; NLGI#2
Housing Style	Pillow Block
Inner Race Heat Treat Method	Case Carburized Inner Ring
Insert Number	RCI-200C
Maximum Operating Temperature (F)	220 °F

General Specifications

UPC	662288493549
Weight	12.57 LB
Packaged Length	10.50 IN
Packaged Width	5.88 IN
Packaged Height	4.13 IN
HTC	8483.20.8080
Country of Origin	United States of America
