• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted felt-lined flinger seal
• Double-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy 2-bolt split cast iron housing

Dimensions

Base Width (in)	2.438 in
Bolt Size (in)	0.625 in
Overall Height (in)	4.625 in
Overall Width (in)	3.5 in
Overall Length (in)	8.875 in
Bore Size (in)	2 in
Centerline to Front Face (in)	1.75 in
Foot Height (in)	1.25 in
Inner Race Length (in)	3.5 in
Base to Center Height (in)	2.25 in
Bolt Center Min (in)	6.313 in
Bolt Center Max (in)	7.188 in
Collar Outer Diameter (in)	3.25 in

Technical Specifications

Rolling Element	Tapered Roller
Insert Material	52100 Bearing Steel
Expansion	No
Housing Base	Solid
Measure Units	Inch
Seal Type	Felt Labyrinth Seal
Housing Material	Cast Iron
Housing Type	Pillow Block, Two Bolt
Housing Construction	Split Two Piece
Radial Dynamic Load Capacity (lb)	8,070 lb
Locking Type	Double Collar Mount
Internal Clearance	Standard
Speed (Max)	2500
Misalignment	±3.0° Misalignment - Static Only
Bore Shape	Straight
End Cap	No
Platform	RPB Series
Bearing Insert Coating	Uncoated
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Replaceable Insert	Yes
Retainer Material	Steel
Housing Color	Gray
Series	RPB
Grease Fitting Thread Size	1/8 NPT
Inner Race Heat Treat Method	Case Carburized Inner Ring
Lubrication Type	Lithium; EP; NLGI#2
Duty/Series	Standard
Ability to Relubricate	Yes
Insert Number	RCI-200
Maximum Operating Temperature (F)	220 °F
Housing Style	Pillow Block

General Specifications

UPC	662288480006
Weight	12.66 LB
Packaged Length	10.50 IN
Packaged Width	5.88 IN
Packaged Height	4.13 IN
HTC	8483.20.8080
Country of Origin	United States of America
