• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted contact flinger seal
• Double-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy 2-bolt split cast iron housing

Dimensions

Base Width (in)	2.313 in
Bolt Size (in)	0.5 in
Overall Height (in)	4.375 in
Overall Width (in)	3.38 in
Overall Length (in)	7.75 in
Bore Size (in)	1.5000 in
Centerline to Front Face (in)	1.688 in
Base to Center Height (in)	2.125 in
Bolt Center Min (in)	5.563 in
Inner Race Length (in)	3.375 in
Bolt Center Max (in)	6.438 in
Foot Height (in)	1.25 in
Collar Outer Diameter (in)	2.875 in

Technical Specifications

Expansion	No
Housing Base	Solid
Measure Units	Inch
Insert Material	52100 Bearing Steel
Seal Type	Single Lip Contact Seal
Housing Material	Cast Iron
Rolling Element	Tapered Roller
Housing Type	Pillow Block, Two Bolt
Housing Construction	Split Two Piece
Internal Clearance	Standard
Bore Shape	Straight
Misalignment	±3.0° Misalignment - Static Only
Speed (Max)	3000
Radial Dynamic Load Capacity (lb)	6,140 lb
Locking Type	Double Collar Mount
Housing Color	Gray
Replaceable Insert	Yes
Outer Ring Land Profile	Standard
Bearing Insert Coating	Uncoated
End Cap	No
Misalignment Type	Static Only
Retainer Material	Steel
Platform	RPB Series
Series	RPB
Grease Fitting Thread Size	1/8 NPT
Inner Race Heat Treat Method	Case Carburized Inner Ring
Insert Number	RCI-108C
Housing Style	Pillow Block
Lubrication Type	Lithium; EP; NLGI#2
Duty/Series	Standard
Ability to Relubricate	Yes
Maximum Operating Temperature (F)	220 °F

General Specifications

UPC	662288493495
Weight	10.90 LB
Packaged Length	9.00 IN
Packaged Width	5.00 IN
Packaged Height	3.38 IN
HTC	8483.20.8080
Country of Origin	United States of America
