• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted contact flinger seal
• Double-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Fluoropolymer-coated 2-bolt split cast iron housing for improved corrosion resistance
• USDA H-1 approved Food-grade grease

Dimensions

Bolt Center-to-Center Length (in)	6 in
Bolt Size (in)	0.5 in
Overall Width (in)	3.38 in
Overall Length (in)	7.75 in
Base Width (in)	2.313 in
Overall Height (in)	4.375 in
Bore Size (in)	1.5000 in
Foot Height (in)	1.25 in
Bolt Center Max (in)	6.438 in
Bolt Center Min (in)	5.563 in
Base to Center Height (in)	2.13 in
Centerline to Front Face (in)	1.688 in
Inner Race Length (in)	3.375 in
Collar Outer Diameter (in)	2.875 in

Technical Specifications

Housing Type	Pillow Block, Two Bolt
Expansion	No
Measure Units	Inch
Seal Type	Single Lip Contact Seal
Rolling Element	Tapered Roller
Housing Material	Flouropolymer Coated Cast Iron
Insert Material	52100 Bearing Steel
Housing Base	Solid
Housing Construction	Split Two Piece
Locking Type	Double Collar Mount
Internal Clearance	Standard
Speed (Max)	3000
Bore Shape	Straight
Radial Dynamic Load Capacity (lb)	6,140 lb
Misalignment	±3.0° Misalignment - Static Only
End Cap	No
Retainer Material	Steel
Outer Ring Land Profile	Standard
Housing Color	Silver/Gray
Options	Corrosion Resistant
Replaceable Insert	Yes
Misalignment Type	Static Only
Bearing Insert Coating	Uncoated
Platform	CR Series
Series	RPB
Grease Fitting Thread Size	1/8 NPT
Duty/Series	Standard
Lubrication Type	Lithium; EP; NLGI#2
Ability to Relubricate	Yes
Housing Style	Pillow Block
Insert Number	RCI-108C FG1
Inner Race Heat Treat Method	Case Carburized Inner Ring
Maximum Operating Temperature (F)	220 °F

General Specifications

UPC	662288816980
Weight	10.90 LB
Packaged Length	9.00 IN
Packaged Width	5.00 IN
Packaged Height	3.38 IN
HTC	8483.20.8080
Country of Origin	United States of America
