• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted felt-lined flinger seal
• Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy split cast iron housing

Dimensions

Bolt Center Diameter (in)	6.5 in
Overall Height (in)	3.313 in
Bolt Center-to-Center Length (in)	4.5960 in
Bolt Size (in)	0.5 in
Overall Width (in)	1.8125 in
Overall Length (in)	7.625 in
Bore Size (in)	2.5000 in
Inner Race Length (in)	3.313 in
Foot Height (in)	0.625 in
Pilot Diameter (in)	5.5 in
Centerline to Front Face (in)	1.875 in
Housing OD (in)	7.625 in
Collar Outer Diameter (in)	3.938 in

Technical Specifications

Insert Material	52100 Bearing Steel
Measure Units	Inch
Seal Type	Felt Labyrinth Seal
Rolling Element	Tapered Roller
Housing Material	Cast Iron
Expansion	Non-Expansion Bearing (Fixed)
Housing Base	Solid
Bore Shape	Straight
Housing Type	Flange, Piloted
Pilot Configuration	With Pilot
Radial Dynamic Load Capacity (lb)	9,030 lb
Misalignment	±3.0° Misalignment - Static Only
Housing Construction	Split Two Piece
Locking Type	Collar Mount
Speed (Max)	2000
Internal Clearance	Standard
Replaceable Insert	Yes
Housing Color	Gray
Outer Ring Land Profile	Standard
Platform	RPB Series
Bearing Insert Coating	Uncoated
End Cap	No
Misalignment Type	Static Only
Retainer Material	Steel
Series	RFPA
Grease Fitting Thread Size	1/8 NPT
Lubrication Type	Lithium; EP; NLGI#2
Insert Number	RCIA-208
Ability to Relubricate	Yes
Maximum Operating Temperature (F)	220 °F
Inner Race Heat Treat Method	Case Carburized Inner Ring
Duty/Series	Standard
Housing Style	Flange Block

General Specifications

UPC	662288483564
Weight	19.00 LB
Packaged Length	8.88 IN
Packaged Width	8.88 IN
Packaged Height	8.63 IN
HTC	8483.20.4080
Country of Origin	United States of America
