• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted felt-lined flinger seal
• Double-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy split cast iron housing

Dimensions

Overall Length (in)	8.75 in
Bolt Center Diameter (in)	7.5 in
Bolt Size (in)	0.625 in
Overall Width (in)	2 in
Bore Size (in)	2.9375 in
Housing OD (in)	8.75 in
Inner Race Length (in)	4.5 in
Centerline to Front Face (in)	2.938 in
Foot Height (in)	0.75 in
Pilot Diameter (in)	6.375 in
Collar Outer Diameter (in)	4.75 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Tapered Roller
Housing Material	Cast Iron
Housing Type	Flange, Piloted
Measure Units	Inch
Expansion	Non-Expansion Bearing (Fixed)
Insert Material	52100 Bearing Steel
Seal Type	Felt Labyrinth Seal
Pilot Configuration	With Pilot
Internal Clearance	Standard
Misalignment	±3.0° Misalignment - Static Only
Speed (Max)	1750
Housing Construction	Split Two Piece
Locking Type	Double Collar Mount
End Cap	No
Outer Ring Land Profile	Standard
Replaceable Insert	Yes
Bearing Insert Coating	Uncoated
Retainer Material	Steel
Platform	RPB Series
Housing Color	Gray
Misalignment Type	Static Only
Series	RFP
Grease Fitting Thread Size	1/8 NPT
Housing Style	Flange Block
Inner Race Heat Treat Method	Case Carburized Inner Ring
Duty/Series	Standard
Insert Number	RCI-215
Maximum Operating Temperature (F)	220 °F
Ability to Relubricate	Yes
Lubrication Type	Lithium; EP; NLGI#2

General Specifications

UPC	662288480600
Weight	26.42 LB
Packaged Length	8.88 IN
Packaged Width	8.88 IN
Packaged Height	8.63 IN
HTC	8483.20.4080
Country of Origin	United States of America
