• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted contact flinger seal
• Double-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy split cast iron housing

Dimensions

Overall Length (in)	7.125 in
Bolt Center Diameter (in)	6 in
Bolt Center-to-Center Length (in)	4.2430 in
Overall Height (in)	3.75 in
Bolt Size (in)	0.5 in
Overall Width (in)	1.6875 in
Bore Size (in)	2.1875 in
Foot Height (in)	0.563 in
Inner Race Length (in)	3.75 in
Pilot Diameter (in)	5 in
Housing OD (in)	7.125 in
Centerline to Front Face (in)	2.438 in
Collar Outer Diameter (in)	3.625 in

Technical Specifications

Housing Material	Cast Iron
Rolling Element	Tapered Roller
Housing Base	Solid
Measure Units	Inch
Insert Material	52100 Bearing Steel
Bore Shape	Straight
Housing Type	Flange, Piloted
Seal Type	Single Lip Contact Seal
Expansion	Non-Expansion Bearing (Fixed)
Pilot Configuration	With Pilot
Misalignment	±3.0° Misalignment - Static Only
Speed (Max)	2500
Radial Dynamic Load Capacity (lb)	8,570 lb
Internal Clearance	Standard
Housing Construction	Split Two Piece
Locking Type	Double Collar Mount
Misalignment Type	Static Only
End Cap	No
Bearing Insert Coating	Uncoated
Platform	RPB Series
Replaceable Insert	Yes
Housing Color	Gray
Retainer Material	Steel
Outer Ring Land Profile	Standard
Series	RFP
Grease Fitting Thread Size	1/8 NPT
Insert Number	RCI 203C
Duty/Series	Standard
Lubrication Type	Lithium; EP; NLGI#2
Maximum Operating Temperature (F)	220 °F
Ability to Relubricate	Yes
Housing Style	Flange Block
Inner Race Heat Treat Method	Case Carburized Inner Ring

General Specifications

UPC	662288494058
Weight	14.26 LB
Packaged Length	7.25 IN
Packaged Width	7.25 IN
Packaged Height	4.25 IN
HTC	8483.20.4080
Country of Origin	United States of America
