• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted felt-lined flinger seal
• Double-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy split cast iron housing

Dimensions

Bolt Center Diameter (in)	5.375 in
Overall Length (in)	6.375 in
Overall Width (in)	1.5625 in
Bolt Size (in)	0.4375 in
Bore Size (in)	2 in
Housing OD (in)	6.375 in
Centerline to Front Face (in)	2.25 in
Foot Height (in)	0.563 in
Pilot Diameter (in)	4.5 in
Inner Race Length (in)	3.5 in
Collar Outer Diameter (in)	3.25 in

Technical Specifications

Insert Material	52100 Bearing Steel
Seal Type	Felt Labyrinth Seal
Bore Shape	Straight
Housing Material	Cast Iron
Measure Units	Inch
Expansion	Non-Expansion Bearing (Fixed)
Rolling Element	Tapered Roller
Housing Type	Flange, Piloted
Pilot Configuration	With Pilot
Locking Type	Double Collar Mount
Misalignment	±3.0° Misalignment - Static Only
Speed (Max)	2500
Housing Construction	Split Two Piece
Internal Clearance	Standard
Retainer Material	Steel
Platform	RPB Series
Housing Color	Gray
Bearing Insert Coating	Uncoated
Misalignment Type	Static Only
End Cap	No
Replaceable Insert	Yes
Outer Ring Land Profile	Standard
Series	RFP
Grease Fitting Thread Size	1/8 NPT
Lubrication Type	Lithium; EP; NLGI#2
Housing Style	Flange Block
Maximum Operating Temperature (F)	220 °F
Ability to Relubricate	Yes
Insert Number	RCI-200
Inner Race Heat Treat Method	Case Carburized Inner Ring
Duty/Series	Standard

General Specifications

UPC	662288480532
Weight	11.60 LB
Packaged Length	6.38 IN
Packaged Width	6.38 IN
Packaged Height	3.63 IN
HTC	8483.20.4080
Country of Origin	United States of America
