• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted contact flinger seal
• Double-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Fluoropolymer-coated split cast iron housing for improved corrosion resistance
• USDA H-1 approved Food-grade grease

Dimensions

Bolt Size (in)	0.4375 in
Overall Width (in)	1.5625 in
Overall Length (in)	6.375 in
Overall Height (in)	3.5 in
Bolt Center-to-Center Length (in)	3.8010 in
Bolt Center Diameter (in)	5.375 in
Bore Size (in)	1.9375 in
Foot Height (in)	0.563 in
Housing OD (in)	6.375 in
Pilot Diameter (in)	4.5 in
Inner Race Length (in)	3.5 in
Centerline to Front Face (in)	1.753 in
Collar Outer Diameter (in)	3.25 in

Technical Specifications

Insert Material	52100 Bearing Steel
Expansion	Non-Expansion Bearing (Fixed)
Rolling Element	Tapered Roller
Bore Shape	Straight
Measure Units	Inch
Housing Material	Flouropolymer Coated Cast Iron
Housing Type	Flange, Piloted
Housing Base	Solid
Seal Type	Single Lip Contact Seal
Pilot Configuration	With Pilot
Radial Dynamic Load Capacity (lb)	8,070 lb
Locking Type	Double Collar Mount
Internal Clearance	Standard
Misalignment	±3.0° Misalignment - Static Only
Housing Construction	Split Two Piece
Speed (Max)	2500
Misalignment Type	Static Only
Bearing Insert Coating	Uncoated
Platform	CR Series
End Cap	No
Options	Corrosion Resistant
Replaceable Insert	Yes
Outer Ring Land Profile	Standard
Retainer Material	Steel
Housing Color	Silver/Gray
Series	RFP
Grease Fitting Thread Size	1/8 NPT
Lubrication Type	Lithium; EP; NLGI#2
Duty/Series	Standard
Maximum Operating Temperature (F)	220 °F
Housing Style	Flange Block
Inner Race Heat Treat Method	Case Carburized Inner Ring
Insert Number	RCI 115C FG1
Ability to Relubricate	Yes

General Specifications

UPC	662288748991
Weight	11.60 LB
Packaged Length	6.38 IN
Packaged Width	6.38 IN
Packaged Height	3.63 IN
HTC	8483.20.4080
Country of Origin	United States of America
