• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted felt-lined flinger seal
• Double-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy split cast iron housing

Dimensions

Bolt Size (in)	0.4375 in
Bolt Center Diameter (in)	5.375 in
Overall Width (in)	1.5625 in
Overall Length (in)	6.375 in
Bore Size (in)	1.9375 in
Inner Race Length (in)	3.5 in
Foot Height (in)	0.563 in
Centerline to Front Face (in)	2.25 in
Housing OD (in)	6.375 in
Pilot Diameter (in)	4.5 in
Collar Outer Diameter (in)	3.25 in

Technical Specifications

Housing Material	Cast Iron
Measure Units	Inch
Seal Type	Felt Labyrinth Seal
Housing Type	Flange, Piloted
Expansion	Non-Expansion Bearing (Fixed)
Rolling Element	Tapered Roller
Insert Material	52100 Bearing Steel
Bore Shape	Straight
Pilot Configuration	With Pilot
Speed (Max)	2500
Misalignment	±3.0° Misalignment - Static Only
Locking Type	Double Collar Mount
Internal Clearance	Standard
Housing Construction	Split Two Piece
Outer Ring Land Profile	Standard
Retainer Material	Steel
Housing Color	Gray
Misalignment Type	Static Only
Platform	RPB Series
End Cap	No
Bearing Insert Coating	Uncoated
Replaceable Insert	Yes
Series	RFP
Grease Fitting Thread Size	1/8 NPT
Duty/Series	Standard
Inner Race Heat Treat Method	Case Carburized Inner Ring
Maximum Operating Temperature (F)	220 °F
Housing Style	Flange Block
Lubrication Type	Lithium; EP; NLGI#2
Insert Number	RCI-115
Ability to Relubricate	Yes

General Specifications

UPC	662288480525
Weight	11.60 LB
Packaged Length	6.38 IN
Packaged Width	6.38 IN
Packaged Height	3.63 IN
HTC	8483.20.4080
Country of Origin	United States of America
