• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted contact flinger seal
• Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy split cast iron housing

Dimensions

Housing Width (in)	5.625 in
Bolt Center Diameter (in)	6.1875 in
Bolt Center-to-Center Length (in)	4.375 in
Overall Width (in)	3.625 in
Bolt Size (in)	0.5 in
Overall Length (in)	5.625 in
Overall Height (in)	3.625 in
Bore Size (in)	2 in
Inner Race Length (in)	2.953 in
Foot Height (in)	1.188 in
Centerline to Front Face (in)	1.75 in
Collar Outer Diameter (in)	3.25 in

Technical Specifications

Rolling Element	Tapered Roller
Bore Shape	Straight
Seal Type	Single Lip Contact Seal
Housing Material	Cast Iron
Expansion	Non-Expansion Bearing (Fixed)
Housing Base	Solid
Insert Material	52100 Bearing Steel
Speed (Max)	2500
Measure Units	Inch
Housing Type	Flange, Four Bolt
Pilot Configuration	No Pilot
Internal Clearance	Standard
Locking Type	Collar Mount
Radial Dynamic Load Capacity (lb)	8,070 lb
Housing Construction	Split Two Piece
Misalignment	±3.0° Misalignment - Static Only
Misalignment Type	Static Only
Platform	RPB Series
Outer Ring Land Profile	Standard
Bearing Insert Coating	Uncoated
Retainer Material	Steel
Housing Color	Gray
Replaceable Insert	Yes
End Cap	No
Series	RFBA
Grease Fitting Thread Size	1/8 NPT
Maximum Operating Temperature (F)	220 °F
Lubrication Type	Lithium; EP; NLGI#2
Duty/Series	Standard
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Case Carburized Inner Ring
Insert Number	RCIA-200C

General Specifications

UPC	662288487944
Weight	12.67 LB
Packaged Length	6.38 IN
Packaged Width	6.38 IN
Packaged Height	3.63 IN
HTC	8483.20.4080
Country of Origin	United States of America
