• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted contact flinger seal
• Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Fluoropolymer-coated split cast iron housing for improved corrosion resistance
• USDA H-1 approved Food-grade grease

Dimensions

Bolt Size (in)	0.5 in
Overall Width (in)	3.625 in
Bolt Center-to-Center Length (in)	4.375 in
Overall Length (in)	5.625 in
Bolt Center Diameter (in)	6.1875 in
Housing Width (in)	5.625 in
Overall Height (in)	3.625 in
Bore Size (in)	2 in
Inner Race Length (in)	3.5 in
Centerline to Front Face (in)	1.75 in
Foot Height (in)	1.188 in
Collar Outer Diameter (in)	3.25 in

Technical Specifications

Expansion	Non-Expansion Bearing (Fixed)
Bore Shape	Straight
Housing Type	Flange, Four Bolt
Housing Base	Solid
Rolling Element	Tapered Roller
Measure Units	Inch
Housing Material	Flouropolymer Coated Cast Iron
Seal Type	Single Lip Contact Seal
Insert Material	52100 Bearing Steel
Speed (Max)	2500
Pilot Configuration	No Pilot
Locking Type	Collar Mount
Misalignment	±3.0° Misalignment - Static Only
Housing Construction	Split Two Piece
Internal Clearance	Standard
End Cap	No
Bearing Insert Coating	Uncoated
Retainer Material	Steel
Options	Corrosion Resistant
Misalignment Type	Static Only
Platform	CR Series
Outer Ring Land Profile	Standard
Replaceable Insert	Yes
Housing Color	Silver/Gray
Series	RFBA
Grease Fitting Thread Size	1/8 NPT
Lubrication Type	Lithium; EP; NLGI#2
Inner Race Heat Treat Method	Case Carburized Inner Ring
Maximum Operating Temperature (F)	220 °F
Housing Style	Flange Block
Insert Number	RCIA-200C FG1
Ability to Relubricate	Yes
Duty/Series	Standard

General Specifications

UPC	662461301555
Weight	14.50 LB
Packaged Length	6.38 IN
Packaged Width	6.38 IN
Packaged Height	3.63 IN
HTC	8483.20.4080
Country of Origin	United States of America
