• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted contact flinger seal
• Double-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews
• Powder coat epoxy split cast iron housing

Dimensions

Bolt Center Diameter (in)	7.609375 in
Bolt Size (in)	0.625 in
Housing Width (in)	6.875 in
Bolt Center-to-Center Length (in)	5.3750 in
Overall Length (in)	6.875 in
Overall Width (in)	4.1875 in
Overall Height (in)	4.188 in
Bore Size (in)	2.2500 in
Foot Height (in)	1.5 in
Centerline to Front Face (in)	2 in
Inner Race Length (in)	4 in
Collar Outer Diameter (in)	3.938 in

Technical Specifications

Expansion	Non-Expansion Bearing (Fixed)
Housing Base	Solid
Measure Units	Inch
Housing Material	Cast Iron
Insert Material	52100 Bearing Steel
Rolling Element	Tapered Roller
Speed (Max)	2000
Housing Type	Flange, Four Bolt
Bore Shape	Straight
Seal Type	Single Lip Contact Seal
Pilot Configuration	No Pilot
Internal Clearance	Standard
Housing Construction	Split Two Piece
Misalignment	±3.0° Misalignment - Static Only
Radial Dynamic Load Capacity (lb)	9,030 lb
Locking Type	Double Collar Mount
Misalignment Type	Static Only
Bearing Insert Coating	Uncoated
Housing Color	Gray
Platform	RPB Series
Retainer Material	Steel
Outer Ring Land Profile	Standard
End Cap	No
Replaceable Insert	Yes
Series	RFB
Grease Fitting Thread Size	1/8 NPT
Duty/Series	Standard
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Case Carburized Inner Ring
Housing Style	Flange Block
Maximum Operating Temperature (F)	220 °F
Insert Number	RCI-204C
Lubrication Type	Lithium; EP; NLGI#2

General Specifications

UPC	662288493839
Weight	24.36 LB
Packaged Length	7.25 IN
Packaged Width	7.25 IN
Packaged Height	4.25 IN
HTC	8483.20.4080
Country of Origin	United States of America
