• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted contact flinger seal
• Single-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews

Dimensions

Overall Width (in)	6.21 in
Bore Size (in)	5 in
Collar OD (in)	3.625 in
Outer Race OD (in)	8.564 in
Outer Race Width (in)	4.5 in

Technical Specifications

Insert Material	52100 Bearing Steel
Rolling Element	Tapered Roller
Bore Shape	Straight
Measure Units	Inch
Housing Type	Insert Only
Speed (Max) (RPM)	1000 rpm
Misalignment	±3.0° Misalignment - Static Only
Internal Clearance	Standard
End Cap	No
Bearing Insert Coating	Uncoated
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Retainer Material	Steel
Platform	RPB Series
Outer Race Profile	Spherical
Inner Race Profile	Wide Inner Ring
Type of Seal	Single Lip Contact Seal
Duty/Series	Standard
Maximum Operating Temperature (F)	220 °F
Inner Race Heat Treat Method	Case Carburized Inner Ring
Lubrication Type	Lithium; EP; NLGI#2
Fixed vs. Expansion	No
Ability to Relubricate	Yes
Locking Type	Collar Mount

General Specifications

UPC	662461294529
Weight	44.40 LB
Packaged Length	12.63 IN
Packaged Width	12.63 IN
Packaged Height	8.13 IN
HTC	8482.20.0064
Country of Origin	United States of America
