• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted contact flinger seal
• Double-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews

Dimensions

Overall Width (in)	5 in
Bore Size (in)	3.4375 in
Outer Race Width (in)	3 in
Outer Race OD (in)	6.1 in
Collar OD (in)	5.438 in

Technical Specifications

Bore Shape	Straight
Housing Type	Insert Only
Rolling Element	Tapered Roller
Measure Units	Inch
Insert Material	52100 Bearing Steel
Internal Clearance	Standard
Radial Dynamic Load Capacity (lb)	15,320 lb
Speed (Max) (RPM)	1500 rpm
Misalignment	±3.0° Misalignment - Static Only
Platform	RPB Series
End Cap	No
Bearing Insert Coating	Uncoated
Retainer Material	Steel
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Outer Ring Width (in)	3 in
Inner Race Profile	Wide Inner Ring
Outer Race Profile	Spherical
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Case Carburized Inner Ring
Type of Seal	Single Lip Contact Seal
Locking Type	Double Collar Mount
Duty/Series	Standard
Maximum Operating Temperature (F)	220 °F
Fixed vs. Expansion	No
Lubrication Type	Lithium; EP; NLGI#2

General Specifications

UPC	662288480907
Weight	20.25 LB
Packaged Length	8.25 IN
Packaged Width	8.25 IN
Packaged Height	7.13 IN
HTC	8482.20.0061
Country of Origin	United States of America
