• Heavy duty tapered roller bearings with steel cage for radial, thrust and combined loading
• Race-mounted felt-lined flinger seal
• Double-collar interlock with 120° spacing setscrew lock, diamond faceted setscrews

Dimensions

Overall Width (in)	4 in
Bore Size (in)	2.4375 in
Outer Race OD (in)	4.4 in
Collar OD (in)	3.938 in
Outer Race Width (in)	2.38 in

Technical Specifications

Insert Material	52100 Bearing Steel
Measure Units	Inch
Bore Shape	Straight
Rolling Element	Tapered Roller
Housing Type	Insert Only
Misalignment	±3.0° Misalignment - Static Only
Radial Dynamic Load Capacity (lb)	9,030 lb
Internal Clearance	Standard
Speed (Max) (RPM)	2000 rpm
Retainer Material	Steel
End Cap	No
Bearing Insert Coating	Uncoated
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Platform	RPB Series
Outer Ring Width (in)	2.38 in
Outer Race Profile	Spherical
Inner Race Profile	Wide Inner Ring
Duty/Series	Standard
Locking Type	Double Collar Mount
Lubrication Type	Lithium; EP; NLGI#2
Ability to Relubricate	Yes
Maximum Operating Temperature (F)	220 °F
Type of Seal	Felt Labyrinth Seal
Inner Race Heat Treat Method	Case Carburized Inner Ring
Fixed vs. Expansion	No

General Specifications

UPC	662288479451
Weight	7.40 LB
Packaged Length	5.19 IN
Packaged Width	5.19 IN
Packaged Height	4.57 IN
HTC	8482.20.0061
Country of Origin	United States of America
