• Sealmaster® custom designed bearing for performance on paving equipment
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	5.75 in
Overall Length (in)	5.75 in
Bolt Size (in)	9/16 in
Overall Height (in)	2.97 in
Bore Diameter (in)	2.1875 in
Foot Height (in)	0.78 in
Length Through Bore (in)	2.82 in
Bolt Spacing (in)	4.4380 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Misalignment Type	Static Only
Housing Color	Black
Outer Ring Land Profile	Standard
Cage Material	Molded fiber glass reinforced nylon
Seal Type	Single Lip Contact Seal with Flinger
Housing Type	Flange, Four Bolt
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Locking Collar Outside Diameter (in)	3 in
Ability to Relubricate	Yes
Radial Clearance	C3 STANDARD
Fixed vs. Expansion	Fixed
Misalignment Capability	±3.0° Misalignment - Static Only
Housing Backside Inner Diameter	4.25
Max Operating Temperature (F)	220 °F
Insert	VE-235
Vibration Frequency Roller Spin	0.0437 cps
Cage Type	Ball Riding Retainer
Bearing Insert Material	52100 Bearing Steel
Size Code	211
Bearing Type	Standard Duty
Vibration Frequency Inner Ring Defect	0.0987 cps
Housing Coating	Powder Coated
Inner Ring Outside Diameter (in)	2.723 in
Static Load Rating (lb)	6,570 lb
Lubricant	Lithium Complex NLGI 2 Grease
Vibration Frequency Outer Ring Defect	0.0680 cps
Vibration Frequency Fundamental Train	0.0068 cps
Maximum Speed (RPM)	2500 rpm
End Cap Available	No
Housing Material	Cast Iron
Grease Fitting Thread Size	1/8 NPT
Shaft Locking Type	Eccentric
Dynamic Load Rating (lb)	9,800 lb

General Specifications

UPC	662461311264
Weight	9.05 LB
Packaged Length	6.75 IN
Packaged Width	6.50 IN
Packaged Height	3.06 IN
HTC	8483.20.4040
Country of Origin	Mexico
