• Sealmaster® custom designed bearing for performance on paving equipment
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Length (in)	5.63 in
Bolt Size (in)	9/16 in
Overall Width (in)	5.63 in
Overall Height (in)	2.156 in
Bore Diameter (in)	1.9375 in
Foot Height (in)	0.56 in
Length Through Bore (in)	2.027 in
Bolt Spacing (in)	4.0000 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Housing Color	Black
Options	High Temperature
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Four Bolt
Seal Type	Multi-Lip Contact Seal
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Locking Collar Outside Diameter (in)	3.47 in
Inner Ring Outside Diameter (in)	2.469 in
End Cap Available	No
Misalignment Capability	±3.0° Misalignment - Static Only
Bearing Insert Material	52100 Bearing Steel
Dynamic Load Rating (lb)	7,889 lb
Bearing Insert Finish	Black Oxide
Radial Clearance	Standard
Shaft Locking Type	Concentric
Cage Type	Land Riding Retainer
Housing Coating	Powder Coated
Fixed vs. Expansion	Fixed
Maximum Speed (RPM)	325 rpm
Insert	SK-1894
Static Load Rating (lb)	5,216 lb
Max Operating Temperature (F)	400 °F
Housing Backside Inner Diameter	4
Lubricant	Lithium; EP; NLGI#2
Bearing Type	Standard Duty
Housing Material	Cast Iron
Size Code	2-115
Grease Fitting Thread Size	1/8 NPT

General Specifications

UPC	662461307076
Weight	6.78 LB
Packaged Length	6.75 IN
Packaged Width	6.50 IN
Packaged Height	2.44 IN
HTC	8483.20.4040
Country of Origin	United States of America
