• Sealmaster® custom designed bearing for performance on paving equipment
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	1/2 in
Overall Width (in)	6.13 in
Overall Length (in)	6.13 in
Overall Height (in)	2.17 in
Bore Diameter (in)	1.9375 in
Foot Height (in)	0.44 in
Length Through Bore (in)	2.17 in
Bolt Spacing (in)	6.1875 in

Technical Specifications

Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Bore Shape	Straight
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Two Bolt
Seal Type	Single Lip Contact Seal
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Locking Collar Outside Diameter (in)	3.47 in
Insert	SK-1894
Inner Ring Outside Diameter (in)	2.469 in
Fixed vs. Expansion	Fixed
Grease Fitting Thread Size	1/8 NPT
Max Operating Temperature (C)	204 °C
Dynamic Load Rating (lb)	7,889 lb
Cage Type	Land Riding Retainer
End Cap Available	No
Housing Coating	Powder Coated
Bearing Insert Finish	Black Oxide
Misalignment Capability	±2.0° Misalignment - Static Only
Size Code	2-115
Shaft Locking Type	Concentric
Max Operating Temperature (F)	400 °F
Radial Clearance	Standard
Housing Material	Cast Iron
Static Load Rating (lb)	5,216 lb
Maximum Speed (RPM)	325 rpm
Bearing Type	Standard Duty
Bearing Insert Material	52100 Bearing Steel
Lubricant	Lithium Complex Grease With Synthetic Oil

General Specifications

UPC	662461243404
Weight	6.59 LB
Packaged Length	6.75 IN
Packaged Width	6.50 IN
Packaged Height	2.44 IN
HTC	8483.20.4040
Country of Origin	United States of America
