• Sealmaster® custom designed bearing for performance on paving equipment
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Length (in)	5.38 in
Overall Width (in)	5.38 in
Bolt Size (in)	9/16 in
Overall Height (in)	2.047 in
Bore Diameter (in)	1.75 in
Foot Height (in)	0.56 in
Length Through Bore (in)	1.934 in
Bolt Spacing (in)	4.125 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Options	High Temperature
Housing Color	Black
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Single Lip Contact Seal
Housing Type	Flange, Four Bolt
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Dynamic Load Rating (lb)	7,901 lb
Inner Ring Outside Diameter (in)	2.307 in
Housing Backside Inner Diameter	3.88
Bearing Type	Standard Duty
Bearing Insert Material	52100 Bearing Steel
Housing Coating	Powder Coated
End Cap Available	No
Fixed vs. Expansion	Fixed
Static Load Rating (lb)	5,139 lb
Housing Material	Cast Iron
Size Code	2-111
Bearing Insert Finish	Black Oxide
Shaft Locking Type	Set Screw
Lubricant	Lithium; EP; NLGI#2
Misalignment Capability	±3.0° Misalignment - Static Only
Max Operating Temperature (F)	400 °F
Insert	SK-2342
Cage Type	Land Riding Retainer
Maximum Speed (RPM)	3800 rpm
Grease Fitting Thread Size	1/4-28
Radial Clearance	Standard

General Specifications

UPC	662461304297
Weight	5.82 LB
Packaged Length	6.06 IN
Packaged Width	5.94 IN
Packaged Height	2.19 IN
HTC	8483.20.4040
Country of Origin	United States of America
