• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• Skwezloc® Concentric locking for near perfect concentricity with fluoropolymer coated collar and corrosion resistant cap screw
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Width (in)	1.75 in
Bore Size (in)	1.2500 in
Outer Race Width (in)	0.938 in
Outer Race OD (in)	2.835 in
Inner Race Length (in)	1.75 in
Centerline to Front Face (in)	1 in
Inner Ring OD (in)	2.438 in
Collar OD (in)	2.438 in

Technical Specifications

Radius	0.04
Measure Units	Inch
Torx Cap Screw	10-24 X 3/4
Rolling Element	Ball Bearing
Housing Type	Insert Only
Insert Material	52100 Bearing Steel, Phosphorus Nickel Coated
Bore Shape	Straight
Speed (Max) (RPM)	2000 rpm
Radial Dynamic Load Capacity (lb)	5,782 lb
Misalignment	±2.0° Misalignment - Static Only
Internal Clearance	Standard
Outer Ring Land Profile	Standard
End Cap	No
Bearing Insert Coating	Phosphorus Nickel Coated
Replaceable Insert	No
Misalignment Type	Static Only
Platform	PN Gold
Certifications	IP69K
Radial Static Load Capacity (lb)	3,493 lb
Cage Material	PPS
Precision Rating	ABEC 1
Outer Race Profile	Spherical
Inner Race Profile	Wide Inner Ring
Maximum Operating Temperature (F)	220 °F
Ability to Relubricate	Yes
Locking Type	Concentric
Inner Race Heat Treat Method	Zone-Hardened
Lubrication Type	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Retainer Type	Land Riding Retainer
Type of Seal	Triple Lip Contact Seal
Duty/Series	Standard
Fixed vs. Expansion	No

General Specifications

UPC	662461348253
Weight	1.50 LB
Packaged Length	3.13 IN
Packaged Width	1.75 IN
Packaged Height	3.13 IN
HTC	8482.10.5052
Country of Origin	Mexico
