• High phosphorous electroless nickel plated 52100 steel for exceptional corrosion resistance
• High performance triple lip contact seal design provides multi-directional sealing with 304 stainless steel body and flinger to minimize contamination ingress and retain lubrication
• Skwezloc® Concentric locking for near perfect concentricity with fluoropolymer coated collar and corrosion resistant cap screw
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Tapered Lands ensures that lubricant will be easily redirected back to the raceway.
• USDA H1 complaint food grade grease

Dimensions

Overall Width (in)	1.438 in
Bore Size (in)	1 in
Outer Race OD (in)	2.047 in
Outer Race Width (in)	0.688 in
Inner Ring OD (in)	1.938 in
Collar OD (in)	1.938 in
Inner Race Length (in)	1.438 in
Centerline to Front Face (in)	0.813 in

Technical Specifications

Rolling Element	Ball Bearing
Torx Cap Screw	8-32 X 5/8
Radius	0.04
Insert Material	52100 Bearing Steel, Phosphorus Nickel Coated
Housing Type	Insert Only
Measure Units	Inch
Bore Shape	Straight
Internal Clearance	Standard
Radial Dynamic Load Capacity (lb)	2,801 lb
Misalignment	±2.0° Misalignment - Static Only
Speed (Max) (RPM)	2700 rpm
Misalignment Type	Static Only
Replaceable Insert	No
End Cap	No
Platform	PN Gold
Bearing Insert Coating	Phosphorus Nickel Coated
Outer Ring Land Profile	Standard
Certifications	IP69K
Radial Static Load Capacity (lb)	1,651 lb
Cage Material	PPS
Precision Rating	ABEC 1
Series	PN-T
Inner Race Profile	Wide Inner Ring
Outer Race Profile	Spherical
Lubrication Type	Calcium Sulfonate NLGI 2 NSF H1 Food Grade Grease
Inner Race Heat Treat Method	Zone-Hardened
Fixed vs. Expansion	No
Maximum Operating Temperature (F)	220 °F
Type of Seal	Triple Lip Contact Seal
Ability to Relubricate	Yes
Duty/Series	Standard
Retainer Type	Land Riding Retainer
Locking Type	Concentric

General Specifications

UPC	662461348222
Weight	0.60 LB
Packaged Length	2.38 IN
Packaged Width	1.44 IN
Packaged Height	2.38 IN
HTC	8482.10.5048
Country of Origin	Mexico
