• Cast iron housed, extended inner ring bearing with ball riding nylon retainer
• Designed to accommodate optional closed or open end to allow users to better conform OSHA requirements for personal protection
• Skwezloc® Concentric locking for near perfect concentricity
• Single lip contact seal and flinger
• Supplied sealed for life with optional lubrication fitting in the box

Dimensions

Overall Length (in)	6.5 in
Overall Width (in)	1.88 in
Overall Height (in)	3.38 in
Base Width (in)	1.88 in
Bolt Size (in)	1/2 in
Bore Diameter (in)	1.1875 in
Foot Height (in)	0.56 in
Base to Center Height (in)	1.6875 in
Length Through Bore (in)	1.56 in
Bolt Spacing Min (in)	4.44 in
Centerline to Outermost Bearing Face (in)	0.98 in
Bolt Spacing Max (in)	5.06 in
Bolt Spacing (in)	4.75 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Base	Solid
Bore Shape	Straight
Housing Construction	One Piece
Housing Color	Black
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Pillow Block, Two Bolt
Seal Type	Single Lip Contact Seal with Flinger
Housing Style	Pillow Block
Locking Collar Outside Diameter (in)	2.23 in
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Dynamic Load Rating (lb)	4,381 lb
Fixed vs. Expansion	Fixed
Misalignment Capability	±2.0° Misalignment - Static Only
Max Operating Temperature (F)	220 °F
Grease Fitting Thread Size	1/4-28
Static Load Rating (lb)	2,567 lb
Bearing Insert Finish	Black Oxide
Vibration Frequency Roller Spin	0.0385 cps
Vibration Frequency Outer Ring Defect	0.0595 cps
Vibration Frequency Fundamental Train	0.0066 cps
Cage Type	Land Riding Retainer
Bearing Insert Material	52100 Bearing Steel
Lubricant	Lithium Complex NLGI 2 Grease
Housing Material	Cast Iron
End Cap Available	No
Housing Coating	Powder Coated
Base Length (in)	6.5 in
Size Code	2-13
Inner Ring Outside Diameter (in)	1.594 in
Vibration Frequency Inner Ring Defect	0.0905 cps
Bearing Type	Standard Duty
Radial Clearance	Standard
Shaft Locking Type	Concentric
Maximum Speed (RPM)	4500 rpm
Insert	MH-19T

General Specifications

UPC	662461340561
Weight	3.75 LB
Packaged Length	4.38 IN
Packaged Width	2.06 IN
Packaged Height	6.81 IN
HTC	8483.20.8040
Country of Origin	Mexico
