• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Height (in)	4.94 in
Overall Width (in)	2.38 in
Base Width (in)	2.38 in
Overall Length (in)	8.63 in
Bolt Size (in)	5/8 in
Bore Diameter (in)	2.1875 in
Base to Center Height (in)	2.4375 in
Foot Height (in)	0.69 in
Length Through Bore (in)	2.25 in
Centerline to Outermost Bearing Face (in)	1.38 in
Bolt Spacing Min (in)	6.5 in
Bolt Spacing Max (in)	7 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Base	Solid
Bore Shape	Straight
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Pillow Block, Two Bolt, Low Base
Seal Type	Felt Labyrinth Seal
Housing Style	Pillow Block
Locking Collar Outside Diameter (in)	3.63 in
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Max Operating Temperature (F)	220 °F
Bearing Insert Finish	Black Oxide
Base Length (in)	8.63 in
Housing Material	Cast Iron
Vibration Frequency Outer Ring Defect	0.068 cps
Radial Clearance	Standard
End Cap Available	No
Size Code	2-23
Housing Coating	Powder Coated
Inner Ring Outside Diameter (in)	2.719 in
Dynamic Load Rating (lb)	9,752 lb
Fixed vs. Expansion	Fixed
Bearing Insert Material	52100 Bearing Steel
Insert	2-23T
Shaft Locking Type	Concentric
Misalignment Capability	±2.0° Misalignment - Static Only
Static Load Rating (lb)	6,601 lb
Bearing Type	Standard Duty
Vibration Frequency Inner Ring Defect	0.0987 cps
Maximum Speed (RPM)	4500 rpm
Vibration Frequency Roller Spin	0.0437 cps
Grease Fitting Thread Size	1/8 NPT
Vibration Frequency Fundamental Train	0.0068 cps
Lubricant	Lithium Complex NLGI 2 Grease
Cage Type	Land Riding Retainer

General Specifications

UPC	662461030639
Weight	9.85 LB
Packaged Length	8.88 IN
Packaged Width	5.94 IN
Packaged Height	2.63 IN
HTC	8483.20.8040
Country of Origin	United States of America
