• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Base Width (in)	1.88 in
Overall Height (in)	3.25 in
Overall Length (in)	6.5 in
Overall Width (in)	1.88 in
Bolt Size (in)	1/2 in
Bore Diameter (in)	1.1875 in
Foot Height (in)	0.44 in
Base to Center Height (in)	1.5625 in
Length Through Bore (in)	1.56 in
Centerline to Outermost Bearing Face (in)	0.98 in
Bolt Spacing (in)	4.75 in
Bolt Spacing Max (in)	5.06 in
Bolt Spacing Min (in)	4.44 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Base	Solid
Bore Shape	Straight
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Single Lip Contact Seal
Housing Type	Pillow Block, Two Bolt, Low Base
Housing Style	Pillow Block
Locking Collar Outside Diameter (in)	2.23 in
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Vibration Frequency Outer Ring Defect	0.0595 cps
Housing Material	Cast Iron
Maximum Speed (RPM)	5450 rpm
Vibration Frequency Roller Spin	0.0385 cps
Housing Coating	Powder Coated
Dynamic Load Rating (lb)	4,381 lb
Misalignment Capability	±2.0° Misalignment - Static Only
Cage Type	Land Riding Retainer
Max Operating Temperature (F)	220 °F
Lubricant	Lithium Complex NLGI 2 Grease
Size Code	2-13
Bearing Type	Standard Duty
Vibration Frequency Fundamental Train	0.0066 cps
Radial Clearance	Standard
Static Load Rating (lb)	2,567 lb
Insert	2-13TC
Shaft Locking Type	Concentric
Bearing Insert Material	52100 Bearing Steel
Base Length (in)	6.5 in
Vibration Frequency Inner Ring Defect	0.0905 cps
Bearing Insert Finish	Black Oxide
Grease Fitting Thread Size	1/4-28
Fixed vs. Expansion	Fixed
Inner Ring Outside Diameter (in)	1.594 in
End Cap Available	No

General Specifications

UPC	662461033562
Weight	3.65 LB
Packaged Length	4.38 IN
Packaged Width	2.06 IN
Packaged Height	6.81 IN
HTC	8483.20.8040
Country of Origin	United States of America
