• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Base Width (in)	1.5 in
Overall Width (in)	1.5 in
Overall Length (in)	5 in
Overall Height (in)	2.5 in
Bolt Size (in)	3/8 in
Bore Diameter (in)	0.75 in
Base to Center Height (in)	1.25 in
Foot Height (in)	0.44 in
Length Through Bore (in)	1.28 in
Bolt Spacing (in)	3.75 in
Centerline to Outermost Bearing Face (in)	0.78 in
Bolt Spacing Max (in)	4.13 in
Bolt Spacing Min (in)	3.38 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Housing Color	Black
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Pillow Block, Two Bolt, Low Base
Seal Type	Single Lip Contact Seal
Housing Style	Pillow Block
Inner Race Heat Treat Method	Zone-Hardened
Locking Collar Outside Diameter (in)	1.8 in
Ability to Relubricate	Yes
Inner Ring Outside Diameter (in)	1.188 in
Insert	2-012TC
Max Operating Temperature (F)	220 °F
End Cap Available	No
Lubricant	Lithium Complex NLGI 2 Grease
Housing Material	Cast Iron
Shaft Locking Type	Concentric
Bearing Type	Standard Duty
Vibration Frequency Fundamental Train	0.0066 cps
Bearing Insert Finish	Black Oxide
Vibration Frequency Roller Spin	0.0381 cps
Vibration Frequency Inner Ring Defect	0.0907 cps
Fixed vs. Expansion	Fixed
Static Load Rating (lb)	1,444 lb
Dynamic Load Rating (lb)	2,611 lb
Vibration Frequency Outer Ring Defect	0.0593 cps
Housing Coating	Powder Coated
Grease Fitting Thread Size	1/4-28
Base Length (in)	5 in
Bearing Insert Material	52100 Bearing Steel
Cage Type	Land Riding Retainer
Radial Clearance	Standard
Misalignment Capability	±2.0° Misalignment - Static Only
Maximum Speed (RPM)	6450 rpm
Size Code	2-012

General Specifications

UPC	662461033524
Weight	1.85 LB
Packaged Length	1.69 IN
Packaged Width	3.19 IN
Packaged Height	5.25 IN
HTC	8483.20.8040
Country of Origin	United States of America
