• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew with diamond faceted setscrews
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Base Width (in)	1.5 in
Overall Height (in)	2.5 in
Overall Width (in)	1.5 in
Overall Length (in)	5 in
Bolt Size (in)	3/8 in
Bore Diameter (in)	0.75 in
Foot Height (in)	0.44 in
Base to Center Height (in)	1.25 in
Length Through Bore (in)	1.28 in
Bolt Spacing Max (in)	4.13 in
Centerline to Outermost Bearing Face (in)	0.78 in
Bolt Spacing Min (in)	3.38 in
Bolt Spacing (in)	3.75 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Base	Solid
Bore Shape	Straight
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Felt Labyrinth Seal
Housing Type	Pillow Block, Two Bolt, Low Base
Housing Style	Pillow Block
Ability to Relubricate	Yes
Locking Collar Outside Diameter (in)	1.8 in
Inner Race Heat Treat Method	Zone-Hardened
End Cap Available	No
Max Operating Temperature (F)	220 °F
Size Code	2-012
Lubricant	Lithium Complex NLGI 2 Grease
Cage Type	Land Riding Retainer
Housing Coating	Powder Coated
Insert	2-012T
Misalignment Capability	±2.0° Misalignment - Static Only
Maximum Speed (RPM)	10200 rpm
Base Length (in)	5 in
Grease Fitting Thread Size	1/4-28
Vibration Frequency Fundamental Train	0.0066 cps
Bearing Type	Standard Duty
Vibration Frequency Roller Spin	0.0381 cps
Dynamic Load Rating (lb)	2,611 lb
Shaft Locking Type	Concentric
Housing Material	Cast Iron
Radial Clearance	Standard
Bearing Insert Finish	Black Oxide
Inner Ring Outside Diameter (in)	1.188 in
Vibration Frequency Outer Ring Defect	0.0593 cps
Vibration Frequency Inner Ring Defect	0.0907 cps
Fixed vs. Expansion	Fixed
Bearing Insert Material	52100 Bearing Steel
Static Load Rating (lb)	1,444 lb

General Specifications

UPC	662461030486
Weight	1.88 LB
Packaged Length	3.19 IN
Packaged Width	1.69 IN
Packaged Height	5.25 IN
HTC	8483.20.8040
Country of Origin	United States of America
