• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Length (in)	8.63 in
Base Width (in)	2.38 in
Overall Height (in)	5.00 in
Overall Width (in)	2.38 in
Bolt Size (in)	5/8 in
Bore Diameter (in)	2.1875 in
Foot Height (in)	0.75 in
Base to Center Height (in)	2.5000 in
Length Through Bore (in)	2.188 in
Bolt Spacing Max (in)	7 in
Centerline to Outermost Bearing Face (in)	1.313 in
Bolt Spacing Min (in)	6.5 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Housing Construction	One Piece
Bore Shape	Straight
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Options	High Temperature
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	High Temp Labyrinth
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Inner Ring Outside Diameter (in)	2.719 in
Vibration Frequency Roller Spin	0.0437 cps
Max Operating Temperature (F)	220 °F
Insert	2-23 AJB
Cage Type	Land Riding Retainer
Radial Clearance	Standard
Dynamic Load Rating (lb)	9,752 lb
Bearing Insert Material	52100 Bearing Steel
End Cap Available	No
Size Code	2-23
Bearing Type	Standard Duty
Housing Coating	Powder Coated
Static Load Rating (lb)	6,601 lb
Misalignment Capability	±2.0° Misalignment - Static Only
Maximum Speed (RPM)	1500 rpm
Base Length (in)	8.63 in
Bearing Insert Finish	Black Oxide
Shaft Locking Type	Set Screw
Housing Material	Cast Iron
Lubricant	Lithium Complex NLGI 2 Grease
Vibration Frequency Outer Ring Defect	0.068 cps
Vibration Frequency Fundamental Train	0.0068 cps
Grease Fitting Thread Size	1/8 NPT
Vibration Frequency Inner Ring Defect	0.0987 cps
Fixed vs. Expansion	Fixed

General Specifications

UPC	662461234624
Weight	9.70 LB
Packaged Length	8.88 IN
Packaged Width	5.94 IN
Packaged Height	2.63 IN
HTC	8483.20.8040
Country of Origin	United States of America
