• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal with black oxide bearing races
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Length (in)	8.63 in
Overall Width (in)	2.38 in
Base Width (in)	2.38 in
Overall Height (in)	5.00 in
Bolt Size (in)	5/8 in
Bore Diameter (in)	2 in
Base to Center Height (in)	2.5000 in
Foot Height (in)	0.75 in
Length Through Bore (in)	2.188 in
Centerline to Outermost Bearing Face (in)	1.313 in
Bolt Spacing Min (in)	6.5 in
Bolt Spacing Max (in)	7 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Housing Color	Black
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Pillow Block, Two Bolt
Seal Type	Single Lip Contact Seal
Housing Style	Pillow Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Size Code	2-23
Base Length (in)	8.63 in
Static Load Rating (lb)	6,601 lb
Bearing Type	Standard Duty
End Cap Available	No
Inner Ring Outside Diameter (in)	2.719 in
Bearing Insert Material	52100 Bearing Steel
Bearing Insert Finish	Black Oxide
Radial Clearance	Standard
Vibration Frequency Fundamental Train	0.0068 cps
Housing Coating	Powder Coated
Shaft Locking Type	Set Screw
Dynamic Load Rating (lb)	9,752 lb
Maximum Speed (RPM)	3250 rpm
Cage Type	Land Riding Retainer
Vibration Frequency Roller Spin	0.0437 cps
Grease Fitting Thread Size	1/8 NPT
Housing Material	Cast Iron
Vibration Frequency Inner Ring Defect	0.0987 cps
Misalignment Capability	±2.0° Misalignment - Static Only
Fixed vs. Expansion	Fixed
Lubricant	Lithium Complex NLGI 2 Grease
Insert	2-2C
Max Operating Temperature (F)	220 °F
Vibration Frequency Outer Ring Defect	0.068 cps

General Specifications

UPC	662461020845
Weight	9.93 LB
Packaged Length	8.88 IN
Packaged Width	5.94 IN
Packaged Height	2.63 IN
HTC	8483.20.8040
Country of Origin	United States of America
