• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew with diamond faceted setscrews
• High temperature felt labyrinth seal and flinger for dry and dusty environment
• Increased internal clearance and high temperature grease
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Length (in)	8.63 in
Overall Width (in)	2.38 in
Overall Height (in)	5.00 in
Base Width (in)	2.38 in
Bolt Size (in)	5/8 in
Bore Diameter (in)	2 in
Base to Center Height (in)	2.5000 in
Foot Height (in)	0.75 in
Length Through Bore (in)	2.1875 in
Bolt Spacing Max (in)	7 in
Bolt Spacing Min (in)	6.5 in
Centerline to Outermost Bearing Face (in)	1.313 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Base	Solid
Bore Shape	Straight
Housing Construction	One Piece
Options	High Temperature
Housing Color	Black
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Pillow Block, Two Bolt
Seal Type	High Temp Labyrinth
Housing Style	Pillow Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Bearing Insert Finish	Black Oxide
Fixed vs. Expansion	Fixed
Cage Type	Land Riding Retainer
Shaft Locking Type	Set Screw
Lubricant	Synthetic NLGI 2 High Temperature Grease
Dynamic Load Rating (lb)	9,752 lb
Radial Clearance	Increased
Misalignment Capability	±2.0° Misalignment - Static Only
Base Length (in)	8.63 in
Vibration Frequency Inner Ring Defect	0.0987 cps
Vibration Frequency Fundamental Train	0.0068 cps
Bearing Type	Standard Duty
Size Code	2-23
Grease Fitting Thread Size	1/8 NPT
Housing Coating	Powder Coated
Insert	2-2 HT
Housing Material	Cast Iron
Static Load Rating (lb)	6,601 lb
Vibration Frequency Roller Spin	0.0437 cps
Vibration Frequency Outer Ring Defect	0.068 cps
Maximum Speed (RPM)	1400 rpm
End Cap Available	No
Inner Ring Outside Diameter (in)	2.719 in
Max Operating Temperature (F)	400 °F
Bearing Insert Material	52100 Bearing Steel

General Specifications

UPC	662461312339
Weight	10.32 LB
Packaged Length	8.88 IN
Packaged Width	5.94 IN
Packaged Height	2.63 IN
HTC	8483.20.8040
Country of Origin	United States of America
