• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Air Handling noise check for quiet operation
• Looser than standard housing fit for ease of alignment on lightweight frames
• Felt labyrinth seal and flinger for dusty and dirty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	2.38 in
Overall Height (in)	4.56 in
Overall Length (in)	8.13 in
Base Width (in)	2.38 in
Bolt Size (in)	5/8 in
Bore Diameter (in)	1.9375 in
Foot Height (in)	0.75 in
Base to Center Height (in)	2.2500 in
Length Through Bore (in)	2.09 in
Centerline to Outermost Bearing Face (in)	1.34 in
Bolt Spacing Min (in)	6 in
Bolt Spacing Max (in)	6.5 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Misalignment Type	Static Only
Options	Air Handling Housing Fit, Noise Tested
Housing Color	Black
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Felt Labyrinth Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Inner Race Heat Treat Method	Zone-Hardened
Locking Collar Outside Diameter (in)	3.38 in
Ability to Relubricate	Yes
Lubricant	Lithium Complex NLGI 2 Grease
Insert	2-115T CXU
Shaft Locking Type	Concentric
Size Code	2-115
Housing Coating	Powder Coated
Vibration Frequency Fundamental Train	0.0068 cps
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Insert Material	52100 Bearing Steel
Maximum Speed (RPM)	5000 rpm
Dynamic Load Rating (lb)	7,889 lb
Radial Clearance	Standard
Bearing Insert Finish	Black Oxide
Grease Fitting Thread Size	1/8 NPT
Vibration Frequency Outer Ring Defect	0.0683 cps
Vibration Frequency Inner Ring Defect	0.0984 cps
Static Load Rating (lb)	5,216 lb
Housing Material	Cast Iron
Cage Type	Land Riding Retainer
Inner Ring Outside Diameter (in)	2.469 in
Fixed vs. Expansion	Fixed
Bearing Type	Standard Duty
Base Length (in)	8.13 in
Max Operating Temperature (F)	220 °F
End Cap Available	No
Vibration Frequency Roller Spin	0.0445 cps

General Specifications

UPC	662461072028
Weight	8.70 LB
Packaged Length	9.00 IN
Packaged Width	5.19 IN
Packaged Height	2.38 IN
HTC	8483.20.8040
Country of Origin	United States of America
