• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Length (in)	8.13 in
Overall Width (in)	2.38 in
Base Width (in)	2.38 in
Overall Height (in)	4.56 in
Bolt Size (in)	5/8 in
Bore Diameter (in)	1.9375 in
Base to Center Height (in)	2.2500 in
Foot Height (in)	0.75 in
Length Through Bore (in)	2.031 in
Centerline to Outermost Bearing Face (in)	1.281 in
Bolt Spacing Min (in)	6 in
Bolt Spacing Max (in)	6.5 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Base	Solid
Bore Shape	Straight
Housing Construction	One Piece
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Single Lip Contact Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Vibration Frequency Fundamental Train	0.0068 cps
Fixed vs. Expansion	Fixed
Bearing Type	Standard Duty
Inner Ring Outside Diameter (in)	2.469 in
Grease Fitting Thread Size	1/8 NPT
Misalignment Capability	±2.0° Misalignment - Static Only
Vibration Frequency Roller Spin	0.0445 cps
Max Operating Temperature (F)	220 °F
Bearing Insert Material	52100 Bearing Steel
Housing Coating	Powder Coated
Static Load Rating (lb)	5,216 lb
Housing Material	Cast Iron
Insert	2-115C
End Cap Available	No
Vibration Frequency Outer Ring Defect	0.0683 cps
Bearing Insert Finish	Black Oxide
Radial Clearance	Standard
Base Length (in)	8.13 in
Vibration Frequency Inner Ring Defect	0.0984 cps
Maximum Speed (RPM)	3550 rpm
Size Code	2-115
Cage Type	Land Riding Retainer
Shaft Locking Type	Set Screw
Lubricant	Lithium Complex NLGI 2 Grease
Dynamic Load Rating (lb)	7,889 lb

General Specifications

UPC	662461020821
Weight	8.20 LB
Packaged Length	9.00 IN
Packaged Width	5.19 IN
Packaged Height	2.38 IN
HTC	8483.20.8040
Country of Origin	United States of America
