• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Extra low drag seal cut down felt labyrinth seal and flinger
• Nylon retainer to reduce overall drag
• Oil lubricated and supplied with an adapter and plug for easy field relubrication
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation
• Looser than standard housing fit for ease of alignment on lightweight frames

Dimensions

Overall Length (in)	7.5 in
Overall Width (in)	2.13 in
Overall Height (in)	4.25 in
Base Width (in)	2.13 in
Bolt Size (in)	1/2 in
Bore Diameter (in)	1.75 in
Foot Height (in)	0.69 in
Base to Center Height (in)	2.13 in
Length Through Bore (in)	2.00 in
Bolt Spacing Min (in)	5.44 in
Centerline to Outermost Bearing Face (in)	1.31 in
Bolt Spacing Max (in)	6.06 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Base	Solid
Bore Shape	Straight
Housing Construction	One Piece
Housing Color	Black
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Options	Extra Low Drag
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Labryinth Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Locking Collar Outside Diameter (in)	2.94 in
Setscrew Torque (in-lbs)	240 in/lbs
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Vibration Frequency Inner Ring Defect	0.0994 cps
Vibration Frequency Roller Spin	0.0417 cps
Base Length (in)	7.50 in
Insert	2-112T XLO
Max Operating Temperature (F)	220 °F
Grease Fitting Thread Size	1/4-28
Cage Type	Land Riding Retainer
Misalignment Capability	±2.0° Misalignment - Static Only
Fixed vs. Expansion	Fixed
Bearing Type	Standard Duty
Shaft Locking Type	Concentric
Vibration Frequency Fundamental Train	0.0067 cps
Maximum Speed (RPM)	1500 rpm
Bearing Insert Finish	Black Oxide
Vibration Frequency Outer Ring Defect	0.0673 cps
Housing Coating	Powder Coated
Size Code	2-111
Housing Material	Cast Iron
End Cap Available	No
Radial Clearance	Standard
Lubricant	Oil Coated Only - No Factory Grease Fill
Bearing Insert Material	52100 Bearing Steel
Inner Ring Outside Diameter (in)	2.063 in
Static Load Rating (lb)	5,139 lb
Dynamic Load Rating (lb)	7,901 lb

General Specifications

UPC	662461321188
Weight	6.90 LB
Packaged Length	5.19 IN
Packaged Width	2.13 IN
Packaged Height	7.81 IN
HTC	8483.20.8040
Country of Origin	United States of America
