• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Length (in)	6.56 in
Overall Height (in)	3.75 in
Base Width (in)	1.88 in
Overall Width (in)	1.88 in
Bolt Size (in)	1/2 in
Bore Diameter (in)	1.4375 in
Foot Height (in)	0.63 in
Base to Center Height (in)	1.875 in
Length Through Bore (in)	1.685 in
Bolt Spacing Max (in)	5.31 in
Bolt Spacing (in)	5 in
Bolt Spacing Min (in)	4.69 in
Centerline to Outermost Bearing Face (in)	1 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Single Lip Contact Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Vibration Frequency Inner Ring Defect	0.0905 cps
Housing Coating	Powder Coated
Radial Clearance	Standard
Bearing Insert Finish	Black Oxide
Grease Fitting Thread Size	1/4-28
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Type	Standard Duty
Size Code	2-17
Insert	2-17C
Maximum Speed (RPM)	4650 rpm
Vibration Frequency Roller Spin	0.0386 cps
Cage Type	Land Riding Retainer
Static Load Rating (lb)	3,493 lb
Base Length (in)	6.56 in
Vibration Frequency Outer Ring Defect	0.0595 cps
Housing Material	Cast Iron
Bearing Insert Material	52100 Bearing Steel
Max Operating Temperature (F)	220 °F
End Cap Available	No
Lubricant	Lithium Complex NLGI 2 Grease
Shaft Locking Type	Set Screw
Inner Ring Outside Diameter (in)	1.851 in
Dynamic Load Rating (lb)	5,782 lb
Vibration Frequency Fundamental Train	0.0066 cps
Fixed vs. Expansion	Fixed

General Specifications

UPC	662461020746
Weight	4.19 LB
Packaged Length	4.38 IN
Packaged Width	2.06 IN
Packaged Height	6.81 IN
HTC	8483.20.8040
Country of Origin	United States of America
