• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew with diamond faceted setscrews
• High temperature felt labyrinth seal and flinger for dry and dusty environment
• Increased internal clearance and high temperature grease
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Length (in)	6.56 in
Base Width (in)	1.88 in
Overall Height (in)	3.75 in
Overall Width (in)	1.88 in
Bolt Size (in)	1/2 in
Bore Diameter (in)	1.4375 in
Foot Height (in)	0.63 in
Base to Center Height (in)	1.875 in
Length Through Bore (in)	1.685 in
Bolt Spacing Max (in)	5.31 in
Bolt Spacing Min (in)	4.69 in
Centerline to Outermost Bearing Face (in)	1 in
Bolt Spacing (in)	5 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Misalignment Type	Static Only
Housing Color	Black
Options	High Temperature
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Pillow Block, Two Bolt
Seal Type	High Temp Labyrinth
Housing Style	Pillow Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Housing Coating	Powder Coated
Lubricant	Synthetic NLGI 2 High Temperature Grease
Size Code	2-17
Cage Type	Land Riding Retainer
Static Load Rating (lb)	3,493 lb
Bearing Insert Finish	Black Oxide
End Cap Available	No
Max Operating Temperature (F)	400 °F
Radial Clearance	Increased
Maximum Speed (RPM)	2200 rpm
Base Length (in)	6.56 in
Bearing Insert Material	52100 Bearing Steel
Fixed vs. Expansion	Fixed
Shaft Locking Type	Set Screw
Vibration Frequency Roller Spin	0.0386 cps
Insert	2-17 HT
Housing Material	Cast Iron
Inner Ring Outside Diameter (in)	1.851 in
Grease Fitting Thread Size	1/4-28
Vibration Frequency Inner Ring Defect	0.0905 cps
Vibration Frequency Fundamental Train	0.0066 cps
Dynamic Load Rating (lb)	5,782 lb
Vibration Frequency Outer Ring Defect	0.0595 cps
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Type	Standard Duty

General Specifications

UPC	662461312704
Weight	4.50 LB
Packaged Length	4.38 IN
Packaged Width	2.06 IN
Packaged Height	6.81 IN
HTC	8483.20.8040
Country of Origin	United States of America
