• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	1.88 in
Overall Height (in)	3.38 in
Base Width (in)	1.88 in
Overall Length (in)	6.5 in
Bolt Size (in)	1/2 in
Bolt Size (mm)	M12 mm
Bore Diameter (mm)	30 mm
Base to Center Height (in)	1.6875 in
Foot Height (in)	0.56 in
Length Through Bore (in)	1.497 in
Centerline to Outermost Bearing Face (in)	0.875 in
Bolt Spacing Min (in)	4.44 in
Bolt Spacing Max (in)	5.06 in
Bolt Spacing (in)	4.75 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Base	Solid
Bore Shape	Straight
Housing Construction	One Piece
Housing Color	Black
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Felt Labyrinth Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Vibration Frequency Outer Ring Defect	0.0595 cps
Max Operating Temperature (F)	220 °F
Vibration Frequency Fundamental Train	0.0066 cps
Vibration Frequency Roller Spin	0.0385 cps
Fixed vs. Expansion	Fixed
Housing Material	Cast Iron
Grease Fitting Thread Size	1/4-28
Vibration Frequency Inner Ring Defect	0.0905 cps
Housing Coating	Powder Coated
Inner Ring Outside Diameter (in)	1.594 in
Bearing Insert Material	52100 Bearing Steel
Static Load Rating (lb)	2,567 lb
Maximum Speed (RPM)	5450 rpm
Radial Clearance	Standard
End Cap Available	No
Insert	5206
Dynamic Load Rating (lb)	4,381 lb
Cage Type	Land Riding Retainer
Bearing Type	Standard Duty
Misalignment Capability	±2.0° Misalignment - Static Only
Base Length (in)	6.5 in
Bearing Insert Finish	Black Oxide
Size Code	2-13
Shaft Locking Type	Set Screw
Lubricant	Lithium Complex NLGI 2 Grease

General Specifications

UPC	662461051771
Weight	3.66 LB
Packaged Length	2.06 IN
Packaged Width	4.38 IN
Packaged Height	6.81 IN
HTC	8483.20.8040
Country of Origin	Mexico
