• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Air Handling noise check for quiet operation
• Looser than standard housing fit for ease of alignment on lightweight frames
• Felt labyrinth seal and flinger for dusty and dirty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Height (in)	3.38 in
Overall Length (in)	6.5 in
Overall Width (in)	1.88 in
Base Width (in)	1.88 in
Bolt Size (in)	1/2 in
Bore Diameter (in)	1.1875 in
Base to Center Height (in)	1.6875 in
Foot Height (in)	0.56 in
Length Through Bore (in)	1.56 in
Bolt Spacing Max (in)	5.06 in
Centerline to Outermost Bearing Face (in)	0.98 in
Bolt Spacing Min (in)	4.44 in
Bolt Spacing (in)	4.75 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Options	Air Handling Housing Fit, Noise Tested
Outer Ring Land Profile	Standard
Housing Color	Black
Misalignment Type	Static Only
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Felt Labyrinth Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Locking Collar Outside Diameter (in)	2.23 in
End Cap Available	No
Shaft Locking Type	Concentric
Size Code	2-13
Radial Clearance	Standard
Bearing Insert Material	52100 Bearing Steel
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Type	Standard Duty
Max Operating Temperature (F)	220 °F
Cage Type	Land Riding Retainer
Vibration Frequency Inner Ring Defect	0.0905 cps
Static Load Rating (lb)	2,567 lb
Maximum Speed (RPM)	7600 rpm
Base Length (in)	6.5 in
Dynamic Load Rating (lb)	4,381 lb
Vibration Frequency Roller Spin	0.0385 cps
Grease Fitting Thread Size	1/4-28
Insert	2-13T CXU
Bearing Insert Finish	Black Oxide
Housing Coating	Powder Coated
Vibration Frequency Outer Ring Defect	0.0595 cps
Fixed vs. Expansion	Fixed
Lubricant	Lithium Complex NLGI 2 Grease
Vibration Frequency Fundamental Train	0.0066 cps
Housing Material	Cast Iron
Inner Ring Outside Diameter (in)	1.594 in

General Specifications

UPC	662461072011
Weight	3.80 LB
Packaged Length	4.38 IN
Packaged Width	2.06 IN
Packaged Height	6.81 IN
HTC	8483.20.8040
Country of Origin	United States of America
