• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Air Handling noise check for quiet operation
• Looser than standard housing fit for ease of alignment on lightweight frames
• Felt labyrinth seal and flinger for dusty and dirty environment
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Height (in)	2.81 in
Overall Width (in)	1.50 in
Base Width (in)	1.50 in
Overall Length (in)	5.5 in
Bolt Size (in)	3/8 in
Bore Diameter (in)	1 in
Foot Height (in)	0.50 in
Base to Center Height (in)	1.4375 in
Length Through Bore (in)	1.438 in
Bolt Spacing Max (in)	4.38 in
Bolt Spacing Min (in)	3.88 in
Centerline to Outermost Bearing Face (in)	0.875 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Misalignment Type	Static Only
Options	Air Handling Housing Fit, Noise Tested
Outer Ring Land Profile	Standard
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Felt Labyrinth Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Inner Race Heat Treat Method	Zone-Hardened
Locking Collar Outside Diameter (in)	1.94 in
Ability to Relubricate	Yes
Static Load Rating (lb)	1,651 lb
Bearing Insert Finish	Black Oxide
Inner Ring Outside Diameter (in)	1.375 in
Size Code	2-015
Vibration Frequency Roller Spin	0.0442 cps
Vibration Frequency Outer Ring Defect	0.0682 cps
Max Operating Temperature (F)	220 °F
Base Length (in)	5.50 in
Vibration Frequency Fundamental Train	0.0068 cps
Bearing Insert Material	52100 Bearing Steel
Lubricant	Lithium Complex NLGI 2 Grease
Grease Fitting Thread Size	1/4-28
Fixed vs. Expansion	Fixed
End Cap Available	No
Maximum Speed (RPM)	9000 rpm
Housing Material	Cast Iron
Bearing Type	Standard Duty
Cage Type	Land Riding Retainer
Dynamic Load Rating (lb)	2,801 lb
Shaft Locking Type	Concentric
Insert	2-1T CXU
Misalignment Capability	±2.0° Misalignment - Static Only
Radial Clearance	Standard
Vibration Frequency Inner Ring Defect	0.0985 cps
Housing Coating	Powder Coated

General Specifications

UPC	662461132951
Weight	2.25 LB
Packaged Length	3.50 IN
Packaged Width	1.69 IN
Packaged Height	5.75 IN
HTC	8483.20.8040
Country of Origin	United States of America
