• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Extra low drag seal cut down felt labyrinth seal and flinger
• Nylon retainer to reduce overall drag
• Oil lubricated and supplied with an adapter and plug for easy field relubrication
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation
• Looser than standard housing fit for ease of alignment on lightweight frames

Dimensions

Overall Length (in)	5.5 in
Overall Width (in)	1.50 in
Overall Height (in)	2.81 in
Base Width (in)	1.50 in
Bolt Size (in)	3/8 in
Bore Diameter (in)	0.9375 in
Foot Height (in)	0.50 in
Base to Center Height (in)	1.4375 in
Length Through Bore (in)	1.375 in
Centerline to Outermost Bearing Face (in)	0.813 in
Bolt Spacing Min (in)	3.88 in
Bolt Spacing Max (in)	4.38 in

Technical Specifications

Rolling Element	Ball Bearing
Housing Base	Solid
Housing Construction	One Piece
Bore Shape	Straight
Misalignment Type	Static Only
Options	Extra Low Drag
Housing Color	Black
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Labryinth Seal
Housing Type	Pillow Block, Two Bolt
Housing Style	Pillow Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Inner Ring Outside Diameter (in)	1.375 in
Size Code	2-015
Housing Coating	Powder Coated
Bearing Insert Material	52100 Bearing Steel
Maximum Speed (RPM)	2500 rpm
Grease Fitting Thread Size	1/4-28
Bearing Type	Standard Duty
Housing Material	Cast Iron
End Cap Available	No
Dynamic Load Rating (lb)	2,801 lb
Vibration Frequency Fundamental Train	0.0068 cps
Radial Clearance	Standard
Vibration Frequency Outer Ring Defect	0.0682 cps
Static Load Rating (lb)	1,651 lb
Shaft Locking Type	Set Screw
Bearing Insert Finish	Black Oxide
Fixed vs. Expansion	Fixed
Vibration Frequency Inner Ring Defect	0.0985 cps
Base Length (in)	5.50 in
Max Operating Temperature (F)	220 °F
Misalignment Capability	±2.0° Misalignment - Static Only
Cage Type	Land Riding Retainer
Lubricant	Oil Coated Only - No Factory Grease Fill
Vibration Frequency Roller Spin	0.0442 cps
Insert	2-015 XLO

General Specifications

UPC	662461297728
Weight	2.20 LB
Packaged Length	3.50 IN
Packaged Width	1.69 IN
Packaged Height	5.75 IN
HTC	8483.20.8040
Country of Origin	United States of America
