• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Height (in)	2.81 in
Base Width (in)	1.50 in
Overall Length (in)	5.5 in
Overall Width (in)	1.50 in
Bolt Size (in)	3/8 in
Bore Diameter (in)	0.875 in
Base to Center Height (in)	1.4375 in
Foot Height (in)	0.50 in
Length Through Bore (in)	1.375 in
Bolt Spacing Min (in)	3.88 in
Bolt Spacing Max (in)	4.38 in
Centerline to Outermost Bearing Face (in)	0.813 in

Technical Specifications

Housing Base	Solid
Rolling Element	Ball Bearing
Bore Shape	Straight
Housing Construction	One Piece
Housing Color	Black
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Pillow Block, Two Bolt
Seal Type	Single Lip Contact Seal
Housing Style	Pillow Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Radial Clearance	Standard
Cage Type	Land Riding Retainer
Lubricant	Lithium Complex NLGI 2 Grease
Max Operating Temperature (F)	220 °F
Static Load Rating (lb)	1,651 lb
Fixed vs. Expansion	Fixed
Bearing Insert Material	52100 Bearing Steel
Shaft Locking Type	Set Screw
End Cap Available	No
Dynamic Load Rating (lb)	2,801 lb
Size Code	2-015
Misalignment Capability	±2.0° Misalignment - Static Only
Maximum Speed (RPM)	6350 rpm
Vibration Frequency Fundamental Train	0.0068 cps
Insert	2-014C
Vibration Frequency Roller Spin	0.0442 cps
Vibration Frequency Outer Ring Defect	0.0682 cps
Grease Fitting Thread Size	1/4-28
Bearing Type	Standard Duty
Vibration Frequency Inner Ring Defect	0.0985 cps
Housing Material	Cast Iron
Base Length (in)	5.50 in
Bearing Insert Finish	Black Oxide
Inner Ring Outside Diameter (in)	1.375 in
Housing Coating	Powder Coated

General Specifications

UPC	662461020647
Weight	2.65 LB
Packaged Length	3.50 IN
Packaged Width	1.69 IN
Packaged Height	5.75 IN
HTC	8483.20.8040
Country of Origin	United States of America
