• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	1 in
Overall Width (in)	10.56 in
Overall Height (in)	5 in
Overall Length (in)	10.56 in
Bore Diameter (in)	3.9375 in
Foot Height (in)	1.25 in
Length Through Bore (in)	4.625 in
Bolt Spacing (in)	8.3125 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Black
Cage Material	Brass
Seal Type	Felt Labyrinth Seal
Housing Type	Flange, Four Bolt
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Max Operating Temperature (F)	220 °F
Insert	3-315
Housing Material	Cast Iron
Fixed vs. Expansion	Fixed
Grease Fitting Thread Size	1/4 NPT
Inner Ring Outside Diameter (in)	5.172 in
End Cap Available	No
Lubricant	Lithium Complex NLGI 2 Grease
Maximum Speed (RPM)	1700 rpm
Bearing Insert Material	52100 Bearing Steel
Shaft Locking Type	Set Screw
Misalignment Capability	±2.0° Misalignment - Static Only
Bearing Type	Medium Duty
Cage Type	Land Riding Retainer
Bearing Insert Finish	Black Oxide
Radial Clearance	Standard
Housing Backside Inner Diameter	7.44
Size Code	2-43
Dynamic Load Rating (lb)	29,905 lb
Static Load Rating (lb)	23,553 lb
Housing Coating	Powder Coated

General Specifications

UPC	662461014745
Weight	56.02 LB
Packaged Length	11.00 IN
Packaged Width	11.00 IN
Packaged Height	6.63 IN
HTC	8483.20.4040
Country of Origin	United States of America
