• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal with black oxide bearing races
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	8.44 in
Bolt Size (in)	3/4 in
Overall Length (in)	8.44 in
Overall Height (in)	3.531 in
Bore Diameter (in)	3.25 in
Foot Height (in)	1 in
Length Through Bore (in)	3.375 in
Bolt Spacing (in)	6.7500 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Misalignment Type	Static Only
Outer Ring Land Profile	Standard
Housing Color	Black
Cage Material	Brass
Housing Type	Flange, Four Bolt
Seal Type	Single Lip Contact Seal
Housing Style	Flange Block
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Insert	2-34C
Housing Coating	Powder Coated
Maximum Speed (RPM)	1850 rpm
Fixed vs. Expansion	Fixed
Misalignment Capability	±2.0° Misalignment - Static Only
Shaft Locking Type	Set Screw
Housing Material	Cast Iron
Bearing Insert Material	52100 Bearing Steel
Lubricant	Lithium Complex NLGI 2 Grease
Max Operating Temperature (F)	220 °F
Cage Type	Land Riding Retainer
End Cap Available	No
Radial Clearance	Standard
Housing Backside Inner Diameter	6
Size Code	2-37
Static Load Rating (lb)	14,496 lb
Inner Ring Outside Diameter (in)	4.156 in
Bearing Insert Finish	Black Oxide
Bearing Type	Medium Duty
Grease Fitting Thread Size	1/4 NPT
Dynamic Load Rating (lb)	18,681 lb

General Specifications

UPC	662461027448
Weight	25.90 LB
Packaged Length	8.75 IN
Packaged Width	8.56 IN
Packaged Height	4.00 IN
HTC	8483.20.4040
Country of Origin	United States of America
