• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	3/4 in
Overall Width (in)	7.75 in
Overall Length (in)	7.75 in
Overall Height (in)	3.5 in
Bore Diameter (in)	2.9375 in
Foot Height (in)	0.88 in
Length Through Bore (in)	3.25 in
Bolt Spacing (in)	6.0000 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Housing Color	Black
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Cage Material	Brass
Seal Type	Single Lip Contact Seal
Housing Type	Flange, Four Bolt
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Inner Ring Outside Diameter (in)	3.922 in
Bearing Insert Material	52100 Bearing Steel
Housing Coating	Powder Coated
Fixed vs. Expansion	Fixed
End Cap Available	No
Shaft Locking Type	Set Screw
Lubricant	Lithium Complex NLGI 2 Grease
Dynamic Load Rating (lb)	17,412 lb
Size Code	2-33
Housing Material	Cast Iron
Max Operating Temperature (F)	220 °F
Maximum Speed (RPM)	1950 rpm
Misalignment Capability	±2.0° Misalignment - Static Only
Cage Type	Land Riding Retainer
Housing Backside Inner Diameter	5.56
Insert	3-215C
Bearing Insert Finish	Black Oxide
Static Load Rating (lb)	13,174 lb
Bearing Type	Medium Duty
Radial Clearance	Standard
Grease Fitting Thread Size	1/4 NPT

General Specifications

UPC	662461027417
Weight	20.71 LB
Packaged Length	8.13 IN
Packaged Width	7.94 IN
Packaged Height	3.50 IN
HTC	8483.20.4040
Country of Origin	United States of America
