• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	5/8 in
Overall Width (in)	6.88 in
Overall Height (in)	2.688 in
Overall Length (in)	6.88 in
Bore Diameter (in)	2.1875 in
Foot Height (in)	0.81 in
Length Through Bore (in)	2.559 in
Bolt Spacing (in)	5.6250 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Outer Ring Land Profile	Standard
Misalignment Type	Static Only
Housing Color	Black
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Four Bolt
Seal Type	Single Lip Contact Seal
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Max Operating Temperature (F)	220 °F
Static Load Rating (lb)	8,150 lb
Misalignment Capability	±2.0° Misalignment - Static Only
Insert	3-23C
Fixed vs. Expansion	Fixed
Cage Type	Land Riding Retainer
Housing Backside Inner Diameter	5
Shaft Locking Type	Set Screw
Housing Coating	Powder Coated
Dynamic Load Rating (lb)	11,789 lb
Bearing Insert Finish	Black Oxide
Grease Fitting Thread Size	1/8 NPT
Bearing Type	Medium Duty
End Cap Available	No
Size Code	2-27
Inner Ring Outside Diameter (in)	2.981 in
Lubricant	Lithium Complex NLGI 2 Grease
Radial Clearance	Standard
Bearing Insert Material	52100 Bearing Steel
Maximum Speed (RPM)	2550 rpm
Housing Material	Cast Iron

General Specifications

UPC	662461027363
Weight	12.15 LB
Packaged Length	7.19 IN
Packaged Width	7.00 IN
Packaged Height	3.31 IN
HTC	8483.20.4040
Country of Origin	United States of America
