• Powder coated epoxy cast iron housing with extended inner ring bearings
• Skwezloc® concentric locking for near perfect concentricity
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Bolt Size (in)	5/8 in
Overall Width (in)	6.38 in
Overall Height (in)	2.375 in
Overall Length (in)	6.38 in
Bore Diameter (in)	2 in
Foot Height (in)	0.81 in
Length Through Bore (in)	2.33 in
Bolt Spacing (in)	5.1250 in

Technical Specifications

Bore Shape	Straight
Rolling Element	Ball Bearing
Pilot Configuration	No Pilot
Housing Construction	One Piece
Misalignment Type	Static Only
Housing Color	Black
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Seal Type	Felt Labyrinth Seal
Housing Type	Flange, Four Bolt
Housing Style	Flange Block
Locking Collar Outside Diameter (in)	3.6 in
Ability to Relubricate	Yes
Inner Race Heat Treat Method	Zone-Hardened
Misalignment Capability	±2.0° Misalignment - Static Only
Housing Coating	Powder Coated
Housing Material	Cast Iron
Radial Clearance	Standard
Inner Ring Outside Diameter (in)	2.723 in
Fixed vs. Expansion	Fixed
Shaft Locking Type	Concentric
Max Operating Temperature (F)	220 °F
Size Code	2-23
End Cap Available	No
Bearing Type	Medium Duty
Housing Backside Inner Diameter	4.25
Bearing Insert Material	52100 Bearing Steel
Static Load Rating (lb)	6,601 lb
Maximum Speed (RPM)	4500 rpm
Lubricant	Lithium Complex NLGI 2 Grease
Insert	2-2T
Dynamic Load Rating (lb)	9,752 lb
Grease Fitting Thread Size	1/8 NPT
Bearing Insert Finish	Black Oxide
Cage Type	Land Riding Retainer

General Specifications

UPC	662461032190
Weight	10.85 LB
Packaged Length	6.75 IN
Packaged Width	6.50 IN
Packaged Height	2.44 IN
HTC	8483.20.4040
Country of Origin	United States of America
