• Powder coated epoxy cast iron housing with extended inner ring bearings
• Zone hardened inner ring with 120° spacing setscrew locking with diamond faceted setscrews
• Single lip contact seal with black oxide bearing races
• Unique land riding retainer design provides superior pocket clearance that allows for 360° grease circulation around the rolling elements resulting in better retained and utilized lubrication.
• Sealmaster® exclusive lock pin and dimple for direct lubrication and anti-rotation

Dimensions

Overall Width (in)	6.38 in
Bolt Size (in)	5/8 in
Overall Length (in)	6.38 in
Overall Height (in)	2.313 in
Bore Diameter (in)	2 in
Foot Height (in)	0.81 in
Length Through Bore (in)	2.19 in
Bolt Spacing (in)	5.1250 in

Technical Specifications

Rolling Element	Ball Bearing
Bore Shape	Straight
Pilot Configuration	No Pilot
Housing Construction	One Piece
Misalignment Type	Static Only
Housing Color	Black
Outer Ring Land Profile	Standard
Cage Material	PPS - Polyphenylene Sulfide
Housing Type	Flange, Four Bolt
Seal Type	Single Lip Contact Seal
Housing Style	Flange Block
Inner Race Heat Treat Method	Zone-Hardened
Ability to Relubricate	Yes
Housing Backside Inner Diameter	4.25
Static Load Rating (lb)	6,601 lb
Radial Clearance	Standard
Housing Coating	Powder Coated
Maximum Speed (RPM)	3250 rpm
Max Operating Temperature (F)	220 °F
Bearing Insert Finish	Black Oxide
Bearing Type	Medium Duty
Insert	2-2C
Lubricant	Lithium Complex NLGI 2 Grease
Misalignment Capability	±2.0° Misalignment - Static Only
Shaft Locking Type	Set Screw
Cage Type	Land Riding Retainer
Dynamic Load Rating (lb)	9,752 lb
Bearing Insert Material	52100 Bearing Steel
Size Code	2-23
Fixed vs. Expansion	Fixed
Housing Material	Cast Iron
Grease Fitting Thread Size	1/8 NPT
End Cap Available	No
Inner Ring Outside Diameter (in)	2.723 in

General Specifications

UPC	662461027356
Weight	10.27 LB
Packaged Length	6.75 IN
Packaged Width	6.50 IN
Packaged Height	2.44 IN
HTC	8483.20.4040
Country of Origin	United States of America
